The IPS TFT LCD has a viewing angle of up to 178 degrees, which means the picture can maintain high color accuracy and clarity when viewed from almost any angle.
If a display can work stably for a long time, not only requires the factory have a various production system (ISO9001/IATF16949/ISO13485) , but also with strict AOI inspection for TFT LCD bonding.
We 100% made AOI during the FOG manufacturing process. The number of conductive particles in IC is at least 5, in FPC is 10.
| Item | Specification |
| LCD Size | 10.1 |
| Number of Pixels | 1280 x 720 |
| Interface | LVDS(40Pin-0.5mm) |
| Brightness(cd/m²) | 1400nits |
| Viewing Direction | Free |
| Pixel Pitch | 0.1755 (H) x 0.1755 (V) |
| Display Colors | 16.7M |
| Active Area | 224.64 (H) x 126.36 (V) |
| Outline Dimension(mm) | 260.00 (H) x 160.00 (V) x 8.15 (D) |
| Operation Temp | -30~85°C |
| Storage Temp | -30~85°C |
| Driver IC | ILI2511 |
| TP Interface | USB&I2C |
| Bonding Type with LCM | OCA Optical Bonding |
