IPS TFT LCDThe IPS TFT LCD has a viewing angle of up to 178 degrees, which means the picture can maintain high color accuracy and clarity when viewed from almost any angle.
- Excellent color reproduction
- Good energy efficiency
- High durability, able to withstand a certain degree of impact and pressure
- The IPS TFT LCD has a faster response speed and can quickly switch between different colors, reducing smearing and afterimages.
-
AOI For Quality Guarantee
If a display can work stably for a long time, not only requires the factory have a various production system (ISO9001/IATF16949/ISO13485) , but also with strict AOI inspection for TFT LCD bonding.
We 100% made AOI during the FOG manufacturing process. The number of conductive particles in IC is at least 5, in FPC is 10.
-
Customize Service
- We made the Cover Glass as your request. LOGO/Color/Shape/Thickness...
- Customize the Backlight, brightness and thickness could be change
- Customize the LCM and CTP pinout
- Customize the interface, TTL/LVDS/MIPI/EDP/DP/HDMI/Type-C/VGA/USB-A
- Customize FPC and Cable
- Customize housing for easier assembly
| Item | Specification |
| LCD Size | 7.0 |
| Number of Pixels | 800*1280 |
| Interface | MIPI(31Pin-0.3mm) |
| Brightness | 450 |
| Viewing Direction | Free |
| Pixel Pitch | 0.117(H)×0.117(V) |
| Display Colors | 16.7M |
| Active Area | 94.2(H)x 150.72(V) |
| Outline Dimension（mm） | 99.71(W)*160.91(H)*2.46 (D) |
| Driver IC | JD9365D |
| Operation Temp | -20~70 |
| Storage Temp | -30~80 |
