15″ Industrial LCD Touch Screen 1920×720 | 1000nit Brightness

这款15英寸工业级液晶显示屏专为严苛环境而设计，可提供卓越的视觉清晰度和交互性能。它拥有独特的1920×720超宽（拉伸）分辨率和高响应电容式触摸面板(TP)，是专业工业界面的理想之选。高达1000尼特的亮度输出确保即使在阳光直射或强烈的户外环境下也能清晰可见。这款显示屏专为全天候24/7连续运行而设计，是户外自助终端、汽车仪表盘和重型工业机械的理想即插即用解决方案。

• 15" Industrial LCD Touch Screen 1920x720 | 1000nit Brightness
• 1000 Nits Sunlight Visibility: High-intensity LED backlighting and 1000 nits brightness ensure perfect visibility in outdoor or bright industrial environments without glare or fading.
• Ultra-Wide 1920x720 Resolution: A unique bar/stretch aspect ratio delivers crisp, high-definition images, maximizing screen space for complex control panels, dashboards, or digital signage.
• Precision Touch Panel (TP) Integration: Equipped with a highly sensitive multi-touch capacitive panel, enabling seamless human-machine interface (HMI) operation, even while wearing industrial gloves or in dusty environments.
• Rugged Industrial-Grade Construction: Designed for harsh environments, featuring a wide operating temperature range, shock resistance, and reliable 24/7 uninterrupted performance.
• Multi-Functional Plug-and-Play Connectivity Options: Supports standard industrial interfaces (HDMI, VGA, LVDS) for easy integration into your existing systems and chassis.

这款工业级液晶显示器配备15英寸超宽屏幕和1000尼特阳光下可视显示屏，具有卓越的适应性。它专为需要耐用、专业显示解决方案的行业而设计。

• Outdoor kiosks and vending machines: High brightness ensures clear readability even in direct sunlight.
• Public transportation and automobiles: 1920x720 resolution is ideal for passenger information systems, bus displays, or train dashboards.
• Industrial automation (human-machine interface): Integrated touch panels allow factory workers to input data and monitor machine status in well-lit, harsh environments.
• Marine and aviation: A wide temperature range and excellent visibility make it ideal for navigation panels.

长期显示稳定性取决于经认证的制造（ISO9001/IATF16949/ISO13485）以及TFT LCD贴合过程中严格的AOI控制。

我们在整个 FOG 制造过程中应用 100% AOI 检测， 以自动检测可能导致间歇性故障的对准问题、污染和粘合缺陷。

为确保可靠的导电性，我们采用明确的标准验证导电颗粒的分布：  IC 区域≥5 个颗粒 ，  FPC 区域≥10 个颗粒。这种过程内 AOI 标准有助于提高一致性、良率和长期可靠性。

• Cover Glass (CG): Logo printing / color / shape / thickness
• Backlight: brightness (nits) / thickness / power optimization
• LCM & CTP: pinout / connector / firmware & touch tuning
• Interface: TTL / LVDS / MIPI / eDP / DP / HDMI / USB-C / VGA / USB-A
• FPC & Cable: FPC design / cable length / connector type
• Housing: custom bracket / front bezel / enclosure for easy assembly
